HOOPS Exchange vs. 3D InterOp by Spatial

When developing engineering applications, CAD data access is a common roadblock. Developers often need to provide support for a wide range of formats, with users demanding both accuracy and speed. In most circumstances, developing and maintaining these capabilities in-house is a prohibitively expensive way to reinvent the wheel, ultimately resulting in a poor imitation of existing solutions. Software development kits (SDKs) allow teams to get market-hardened features with a fraction of the development effort.

When developers research the best CAD data access toolkits, two of the biggest names that will come up are Tech Soft 3D’s HOOPS Exchange and 3D InterOp by Spatial, owned by Dassault Systèmes. While open-source and low-budget options exist, these two SDKs offer the highest quality and breadth of translation for many use cases.

Here, we wanted to provide an honest breakdown of the two, offering our 30 years of experience serving this market to discuss relative strengths, limitations, and who they might be right for.

Of course, one of the most common questions regarding data access is format support: jump to the end for a table directly comparing the two toolkits read/write support for various formats.

Common Strengths of HOOPS Exchange & 3D InterOp by Spatial

As premium CAD data translation toolkits, both HOOPS Exchange and 3D InterOp by Spatial will provide a high level of quality, speed, and vendor support that open source and low-budget alternatives cannot match. Beyond broader quality and speed, there are a few specific capabilities to highlight that the toolkits share.

Reliable Integration with HOOPS Visualize

HOOPS Visualize offers developers multiple ways to provide their tool with the industry-leading graphics functionality they need, from desktop, XR, and mobile to web-native applications. As the name suggests, the toolkit is a part of the HOOPS product line, so it integrates natively with HOOPS Exchange. Despite competing on some fronts, Tech Soft 3D and Spatial maintain a close working relationship, with Spatial being a reseller of HOOPS Visualize.

As a result, 3D InterOp also supports integration with HOOPS Visualize. No matter which CAD data translation toolkit you choose, combining it with a proven graphics SDK is going to be simple and well supported.

Global Support for a Global Market

Both Tech Soft 3D and Spatial have offices all over the world, allowing you to get support where you need it from those who understand your unique challenges. For both regional and global organizations, the technical and business support you will get from these two toolkit providers will far surpass that from smaller providers or open-source alternatives.

Modeling Kernel Provided for Your Development Needs

Both vendors can provide a modeling kernel alongside their translation toolkit. Spatial develops its own kernels, ACIS and CGM, while Tech Soft 3D is a reseller of Siemens Parasolid, the industry’s leading solid modeling kernel. HOOPS Exchange includes a dedicated Parasolid integration, so either way you can license translation and modeling from a single partner.

HOOPS Exchange Key Strengths

While both toolkits offer powerful data translation for developers, there are key areas where each product has a unique benefit. First, some of the strengths of HOOPS Exchange.

High-Fidelity Access to 3D Data

The core of the HOOPS Exchange design philosophy is data access, not data translation. Translating a sentence from French to English means reinterpreting it, but engineers will tell you that 3D geometry should never be reinterpreted. What comes out should match exactly what went in.

HOOPS Exchange is built to provide access to geometry, structure and visualization data without modifying the underlying information. That focus on fidelity has made it the go-to choice for PLM, BIM, digital twin, XR and other industries where accurate 3D viewing is essential. Industry leaders including Ansys, Siemens, Hexagon, NVIDIA Omniverse, Unreal Engine and Unity build on HOOPS Exchange.

Fast, Lightweight and Up-to-Date

HOOPS Exchange offers best-in-class reading speed, minimal memory consumption and a small DLL size. It runs on Windows, Linux, macOS, Mac Catalyst (experimental), iOS and Android, and developers can work in C++ or through its C# API.

Keeping pace with CAD vendors matters just as much as speed. HOOPS Exchange ships on a six-week release cadence, and we aim to update our CATIA V5, SOLIDWORKS, Creo and NX readers within 90 days of each new CAD release. Our public roadmap shows what’s coming next. For teams where performance, platform coverage and up-to-date format support are top priorities, HOOPS Exchange is likely the best choice.

Support for Next-Generation and Innovative Applications

Supporting organizations developing applications at the forefront of their fields requires data access technology that is open and neutral to various CAD vendors. HOOPS Exchange uses PRC, an ISO standard, as its internal data representation, rather than a proprietary, closed format. The format is also the basis of 3D representation within PDFs, developed as part of a close partnership with Adobe. This provides maximum transparency and flexibility for data representation and storage. With HOOPS Publish now consolidated into HOOPS Exchange, developers can also publish 3D PDFs using the same toolkit.

For 3D data, while we still believe in the importance of B-Rep, we’re seeing more non-B-Rep inputs, such as point clouds and implicit models. We are also seeing the ever-increasing role that metadata, physically based materials (PBR), CAD features, mass property info, PMI, and constraints are playing in the market. The rising influence of formats like USD, glTF, and 3MF are examples of these trends in action.

HOOPS Exchange supports these formats, including read and write support for glTF and 3MF, and USD export (currently experimental), because it is independent of B-Rep modeling SDKs. NVIDIA’s Omniverse platform, built on USD, already uses HOOPS Exchange for its CAD Converter Extension. We continue to add formats as the market evolves, with recent releases adding DGN, Navisworks NWC, and a beta reader for QIF. We believe that this provides a unique position in the market to provide toolkits for innovative applications. The toolkit is neutral and unbiased in the way it supports data access because Tech Soft 3D is an independent vendor, not tied to any 3D CAD leader like Dassault Systèmes, Autodesk, PTC, or Siemens.

Applications developed with toolkits provided by one of these organizations may face significant challenges to their neutrality. While 3D InterOp by Spatial is a powerful toolkit, they are a part of Dassault Systèmes, and this could potentially create issues related to neutrality.

From CAD Data to AI: HOOPS AI

Machine learning on engineering data starts with getting at the CAD data itself. Reading dozens of formats, keeping the B-rep and topology intact, and turning thousands of models into clean training sets is where most AI projects stall.

For more on why CAD data is the starting point for AI in engineering, see our blog, Unlocking the Power of CAD Data in AI.

HOOPS AI is built to solve that problem. It brings HOOPS Exchange’s CAD translation into Python, giving data scientists and ML engineers direct access to geometry, topology and assemblies across the same 30+ formats HOOPS Exchange supports, without needing CAD software. From there, it handles the parts of the pipeline that usually eat up development time: organizing and cleaning datasets, encoding CAD data for machine learning, and training models with pre-built architectures or your own.

HOOPS AI is now generally available on Windows and Linux. The latest release, HOOPS AI 1.1, adds shape intelligence capabilities for part similarity and design reuse. Partners such as Synera are already using it to bring CAD-aware AI into their applications.

If your roadmap includes AI, the same data access layer that powers your application today can also power your machine learning work. Explore HOOPS AI

Support for Parasolid-Based Applications

HOOPS Exchange has a strong integration with Siemens Parasolid, the leading solid modeling kernel. HOOPS Exchange includes the Parasolid integration module, helping engineers get the best quality 3D CAD data translation into Parasolid. Siemens Digital Industries Software resells HOOPS Exchange. Developers working with Siemens can already simply ask their contact to get started with HOOPS Exchange. As we discussed in 5 Myths of CAD Data Translation, we recommend building on the Parasolid modeling kernel for high-level CAD data integrity. Tech Soft 3D is also a proud reseller of Parasolid, so we are perfectly placed to help you through any issues that might come up working with the two products.

According to Siemens, 45% of the 3D CAD data used in the mechanical market is Parasolid-based. Focusing on Parasolid data is one way developers can get an advantage in a competitive market, and we have outlined some of the reasons in our blog “7 Reasons to Consider Switching Modeling Kernels to Parasolid.”

3D InterOp by Spatial Key Strengths

While we obviously love HOOPS Exchange, 3D InterOp by Spatial has a few core strengths we want to highlight. Many of these stem from the reality of coming from such a large organization, an attribute with both pros and cons.

The Perks of Large Organization Ownership

As discussed, Spatial is a part of Dassault Systèmes. While this may cause some issues with neutrality, it comes with the undeniable benefits of being a part of such an innovative, powerful company. Spatial has access to its powerful modeling technologies and extensive R&D resources. Simply put, the size, reputation, and skill of their development team will lead you to expect cutting-edge technology and support when you license their products.

Dassault Systèmes is a leader in the PLM market, wielding substantial influence. Although Spatial is not a part of the 3DEXPERIENCE platform, Spatial will still benefit from the significant market penetration that comes with this. They also have the benefits that come from co-marketing opportunities with the DS logo. For organizations that choose to license their toolkits, this recognition provides proof to your end users that the application is built with a name they likely already know.

AGM & Application Starter Tools

Along with their toolkit offerings, Spatial provides AGM, a multifaceted application framework that helps developers create robust 3D applications. AGM includes source code, training, and project files, and gives developers access to Spatial’s SDKs as well as the HOOPS Visualize APIs. Spatial claims that this can help to further reduce time-to-market and development costs.

Tech Soft 3D takes a different approach, using the following resources to help teams streamline their application development process as much as possible. These resources include:

  • Tech Soft 3D Labs – Experimental projects with tons of source code available at no additional cost

  • Tech Soft 3D Forum – Our partners and Tech Soft 3D staff collaborate, openly sharing ideas, guides, instructions, and source code snippets to help each other as a community.

  • Tech Soft 3D YouTube – Video guides to help your team learn

  • HOOPS Demo Viewer – A powerful tool for testing, debugging, and more

  • HOOPS Learning Platform – Modules to help learn more about HOOPS toolkits

  • HOOPS Exchange Documentation – Detailed format, platform, and data support, including known limitations

  • Samples distributed with the SDKs

Ultimately, we believe that both approaches greatly help you jumpstart your development and go to the market faster.

HOOPS Exchange vs. 3D InterOp by Spatial: Which is Right for You?

The choice between these two toolkits is going to boil down to your unique needs and the markets you intend to serve. Both offer a premium CAD data translation toolkit and are rightfully at the top of the industry for developers looking for the best-of-the-best. The best next step is to get in touch and help us learn more about your unique data access needs.

Format Support Comparison Table

The table below gives a broad overview of read/write support in HOOPS Exchange and 3D InterOp by Spatial. For HOOPS Exchange, our documentation breaks down supported versions, platforms, tessellation, B-Rep, PMI and more for each format. For 3D InterOp, see Spatial’s format list. See the notes below the table for details on how we compiled it.

Format / Family HOOPS Exchange Read HOOPS Exchange Write 3D InterOp Read 3D InterOp Write Notes / Industry Context
3D PDF / PRC ✅ ✅1 – – Documentation, review and lightweight 3D; strong in PLM
3MF ✅ ✅ ✅ ✅ Open standard for additive manufacturing
ACIS ✅ ✅ ✅ ✅ Solid modeling exchange
AutoCAD 2D (.dwg / .dxf) ✅ – ✅ ✅2 Widely used in AEC and mechanical design
AutoCAD 3D (.dwg / .dxf) ✅ – ✅ – Widely used in AEC and mechanical design
Autodesk 3DS (.3ds) ✅ – – – 3D visualization, graphics and animation
Autodesk DWF (.dwf / .dwfx) ✅ – – – Lightweight CAD publishing
Autodesk Inventor (.ipt / .iam) ✅ – ✅ – Mechanical design
Autodesk Navisworks (.nwd / .nwc) ✅ – ✅ – Large model review for AEC and infrastructure
AVEVA E3D / PDMS (.rvm) – – ✅ – Plant and marine design
CATIA V4 ✅ – ✅ ✅3, 10 Legacy aerospace and automotive
CATIA V5 (incl. CATDrawing, CGR) ✅ – ✅ ✅ Dominant in aerospace and automotive
CATIA V6 / 3DEXPERIENCE (3DXML) ✅ – ✅9 ✅4 Part of the DS ecosystem
COLLADA (.dae) ✅ – ✅ ✅ Visualization and graphics
Creo / Pro/E ✅ – ✅ – Widely used mechanical CAD
DGN / MicroStation ✅ – ✅ – Infrastructure and civil projects
FBX ✅ ✅ ✅ ✅ Visualization, AR/VR, gaming
glTF / GLB ✅ ✅ – ✅ Modern 3D graphics and web workflows
Hexagon Smart 3D – – ✅ – Plant design and industrial projects
HTML – ✅ – – Interactive 3D in a browser
I-deas ✅ – – – Legacy NX/I-deas projects
IFC ✅ – ✅ ✅ BIM exchange for construction and architecture
IGES ✅ ✅ ✅ ✅ Neutral CAD exchange
JT ✅ ✅ ✅ – Lightweight CAD for visualization and PLM
NX / Unigraphics (.prt) ✅ – ✅ – Mechanical design and PLM
OBJ ✅ ✅ ✅ ✅ Visualization
Parasolid ✅ ✅ ✅ ✅5 Core solid modeling interoperability
QIF ✅6 – – – Quality and metrology data
Revit (.rvt / .rfa) ✅ – ✅ ✅7 BIM for architecture and construction
Rhino3D ✅ – ✅ – Architecture and industrial design
Solid Edge ✅ – ✅ – Mechanical CAD
SOLIDWORKS ✅ – ✅ – Widely used mechanical CAD
STEP ✅ ✅ ✅11 ✅11 Neutral standard; essential for cross-CAD interoperability
STEP/XML ✅ – ✅ –12 XML variant of STEP
STL ✅ ✅ ✅ ✅ 3D printing and manufacturing
U3D ✅ ✅ – – Lightweight 3D, PLM review
USD / USDA – ✅8 – – Modern visualization and AR/VR pipelines
VDA-FS ✅ – ✅ ✅10 Automotive exchange
VRML ✅ ✅ – – Visualization
XCGM – – ✅ ✅ Dassault CGM exchange format

1 - 3D PDF export requires the HOOPS Exchange Advanced Publishing module.
2 - 2D drawing sheets only.
3 - Parts only.
4 - 3DXML, tessellated only.
5 - Requires a Parasolid installation.
6 - Beta.
7 - Revit families (.rfa) only.
8 - Experimental; Windows x64 and Linux x64 only.
9 - Exported files only (3DEXPERIENCE has no native file format of its own).
10 - Not available in the 3D InterOp CGM edition.
11 - Semantic PMI in AP242 requires an additional Spatial license.
12 - Spatial lists .stpx among its STEP extensions but does not state whether STEP/XML can be written.



Last updated November 2026. HOOPS Exchange support is taken from our documentation, which details supported versions, platforms, B-rep, PMI and tessellation for every format, including known limitations. 3D InterOp support reflects our reading of Spatial's publicly available format list (version 2026 1.0.1). Some 3D InterOp capabilities depend on which modeler edition or additional licenses you use, and not every capability is documented publicly, so we recommend confirming specific requirements with Spatial directly.

HOOPS Exchange & 3D InterOp FAQs

What is the difference between HOOPS Exchange and 3D InterOp?

Both are premium CAD data translation SDKs that give developers access to more than 30 CAD formats. HOOPS Exchange focuses on data access without modification, with fast reading speeds, a small footprint, and support for newer formats like USD, glTF, and 3MF. It is developed by Tech Soft 3D, an independent vendor. 3D InterOp is developed by Spatial, part of Dassault Systèmes, and places a stronger emphasis on geometry repair and on output to Spatial’s own ACIS and CGM modeling kernels.

Which CAD formats does HOOPS Exchange support?

HOOPS Exchange reads more than 30 formats, including CATIA, SOLIDWORKS, NX, Creo, Inventor, Solid Edge, Revit, IFC, STEP, and JT. It can also write formats such as STEP, IGES, JT, Parasolid, glTF, 3MF, 3D PDF, and USD (experimental). See the comparison table above, or our documentation for supported versions, platforms, and data types for each format.

Does HOOPS Exchange work with Parasolid?

Yes. HOOPS Exchange includes a Parasolid integration module for translating CAD data directly into a Parasolid session. Data from Parasolid-based systems such as NX, Solid Edge, and SOLIDWORKS is read using Parasolid itself, with no translation involved. Tech Soft 3D is also a reseller of Siemens Parasolid.

How can I evaluate HOOPS Exchange?

You can sign up for a free 60-day evaluation of HOOPS Exchange through our developer dashboard, which includes access to documentation, samples, and our technical team. We encourage you to test HOOPS Exchange with your own data, and to compare it with your current toolkit for both speed and accuracy.
