Build your CAE application with fail-free 2D and 3D meshing you can count on. HOOPS Mesh delivers exact predicate technology and best-in-class boundary recovery for unmatched precision.
With over 20 years of experience, HOOPS Mesh is a toolkit CAE developers rely on for fully automatic, high-quality mesh generation. Through a single, unified programming interface, it delivers planar triangular meshes, 2.5D triangular and quadrilateral surface meshes, tetrahedral volume meshes, mapped and extrusion meshes, and hybrid volume meshes with pyramidal transitions from quad surfaces to tetrahedral interiors.
All components work together to support advanced workflows, like generating conformal meshes on complex geometries. Trusted by industry leaders, HOOPS Mesh brings unmatched reliability and flexibility to simulation software development.
Features & Functionality
The HOOPS Mesh software component empowers your engineering teams to seamlessly integrate robust mesh generation in your CAE application.
Mesh generation can run into tricky edge cases like tiny element values or nearly overlapping nodes, causing some meshers to fail. HOOPS Mesh tackles these challenges seamlessly with exact arithmetic and a hardened boundary recovery scheme, ensuring reliable 2D and 3D meshing even on complex geometries.
HOOPS Mesh supports both linear and curved elements across all mesh generators, in addition to advanced cubic elements for unstructured meshing. Unlike many other meshers, HOOPS Mesh has the unique ability to take parabolic triangles as input. With built-in logic to handle curved geometry from the beginning, HOOPS Mesh is able to deliver stable, high-quality parabolic tetrahedral meshes.
With HOOPS Mesh, developers have full control over mesh size and element quality. Mesh size can be localized by selecting specific model regions, setting a depth from the boundary, or defining custom rules via callbacks. Surface quality controls include skew angle, quadrilateral warp, edge length, and triangle altitude ratio, ensuring cleaner, more reliable meshes. This level of control streamlines meshing and delivers more accurate simulation results.
Bridge the gap between CAD data and CAE workflows by combining HOOPS Mesh with HOOPS Exchange, Tech Soft 3D’s leading SDK for accessing over 30 CAD formats. HOOPS Mesh also provides sample integration source code for popular kernels, such as Parasolid, Open CASCADE, and ACIS, to make integration with them smoother.
The 2.5D surface mesher starts with a triangular tessellation of geometric surfaces. Users can attach any number of associations to the mesh. Thanks to its underlying geometry representation, HOOPS Mesh easily integrates with industry-standard kernels.
Along with the main hybrid advancing front/Delaunay tetrahedral generator, HOOPS Mesh offers a variety of other possibilities, including mapped-mesh and extrusion generators. Triangular, quadrilateral, tetrahedral, wedge, pyramidal, and hexahedral elements can be generated.
The power of the toolkit lies in its flexible interface, which allows a seamless combination of the various meshers to produce complex meshing workflows.
